RGE1100

Product Parameter

Type

Polymeric

Series

PolySwitch®

Ratings

-

Approvals

CSA, TUV, UL

Packaging

Bulk

Part Status

Obsolete

Lead Spacing

0.199" (5.05mm)

Time to Trip

7s

Current - Max

100A

Mounting Type

Through Hole

Voltage - Max

16V

Package / Case

Radial, Disc

Thickness (Max)

-

Size / Dimension

0.669" L x 0.098" W (17.00mm x 2.50mm)

Current - Trip (It)

18.7A

Height - Seated (Max)

1.024" (26.00mm)

Operating Temperature

-

Current - Hold (Ih) (Max)

11A

Resistance - Initial (Ri) (Min)

3.7 mOhms

Resistance - Post Trip (R1) (Max)

8.9 mOhms
