LR4-190LF

Product Parameter

Type

Polymeric

Series

PolySwitch®, LR4

Ratings

-

Approvals

CSA, TUV, UL

Packaging

Bulk

Part Status

Obsolete

Lead Spacing

-

Time to Trip

5s

Current - Max

100A

Mounting Type

User Defined

Voltage - Max

15V

Package / Case

Strap

Size / Dimension

1.161" L x 0.205" W (29.50mm x 5.20mm)

Current - Trip (It)

3.9A

Operating Temperature

-40°C ~ 85°C

Current - Hold (Ih) (Max)

1.9A

Resistance - Initial (Ri) (Min)

39 mOhms

Resistance - Post Trip (R1) (Max)

102 mOhms
