Lanka Micro
8214JH4
| Manufacturer: | ebm-papst Inc. |
In Stock 573 pcs
|
|
|---|---|---|---|
| Datasheet: | 8214JH4 | ||
| Product Category: | DC Brushless Fans (BLDC) | Reference Price (In US Dollars) | 1pcs |
| Description: | FAN AXIAL 80X38MM 24VDC WIRE | $78.99 | |
Fill out the below form and we will contact you as soon as possible.
You May Also Be Interested In
Product Parameter
- RPM
- 14000 RPM
- Noise
- 71.0 dB(A)
- Width
- 38.00mm
- Series
- 8200J
- Weight
- 0.441 lb (200.03 g)
- Air Flow
- 131.0 CFM (3.67m³/min)
- Fan Type
- Tubeaxial
- Features
- -
- Approvals
- -
- Part Status
- Active
- Termination
- 2 Wire Leads
- Bearing Type
- Ball
- Power (Watts)
- 38.00W
- Voltage Range
- 12 ~ 27.6VDC
- Static Pressure
- -
- Voltage - Rated
- 24VDC
- Lifetime @ Temp.
- 50000 Hrs @ 40°C
- Material - Blade
- Polyamide (PA), Nylon, Fiberglass Reinforced
- Material - Frame
- Polybutylene Terephthalate (PBT), Fiberglass Reinforced
- Size / Dimension
- Square - 80mm L x 80mm H
- Ingress Protection
- -
- Current Rating (Amps)
- -
- Operating Temperature
- -4 ~ 158°F (-20 ~ 70°C)
