SQM40010EL_GE3
| Manufacturer: | Vishay / Siliconix |
In Stock 673 pcs
|
|
|---|---|---|---|
| Datasheet: | SQM40010EL_GE3 | ||
| Product Category: | Transistors - FETs, MOSFETs - Single | Reference Price (In US Dollars) | 1pcs |
| Description: | MOSFET N-CH 40V 120A D2PAK | Inquiry | |
Fill out the below form and we will contact you as soon as possible.
You May Also Be Interested In
Product Parameter
- Series
- Automotive, AEC-Q101, TrenchFET®
- FET Type
- N-Channel
- Packaging
- Digi-Reel®
- Vgs (Max)
- ±20V
- Technology
- MOSFET (Metal Oxide)
- FET Feature
- -
- Part Status
- Active
- Mounting Type
- Surface Mount
- Package / Case
- TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
- Vgs(th) (Max) @ Id
- 2.5V @ 250µA
- Operating Temperature
- -55°C ~ 175°C (TJ)
- Rds On (Max) @ Id, Vgs
- 1.6mOhm @ 30A, 10V
- Power Dissipation (Max)
- 375W (Tc)
- Supplier Device Package
- D²PAK (TO-263)
- Gate Charge (Qg) (Max) @ Vgs
- 230nC @ 10V
- Drain to Source Voltage (Vdss)
- 40V
- Input Capacitance (Ciss) (Max) @ Vds
- 17100pF @ 20V
- Current - Continuous Drain (Id) @ 25°C
- 120A (Tc)
- Drive Voltage (Max Rds On, Min Rds On)
- 4.5V, 10V
