RUSB120

Product Parameter

Type

Polymeric

Series

PolySwitch®

Ratings

-

Approvals

CSA, TUV, UR

Packaging

Bulk

Part Status

Obsolete

Lead Spacing

0.201" (5.10mm)

Time to Trip

500ms

Current - Max

40A

Mounting Type

Through Hole

Voltage - Max

6V

Package / Case

Radial, Disc

Thickness (Max)

-

Size / Dimension

0.272" Dia x 0.122" T (6.90mm x 3.10mm)

Current - Trip (It)

2A

Height - Seated (Max)

0.461" (11.70mm)

Operating Temperature

-

Current - Hold (Ih) (Max)

1.2A

Resistance - Initial (Ri) (Min)

70 mOhms

Resistance - Post Trip (R1) (Max)

140 mOhms
