H/MS08A22-22S-DT12D(73)
Manufacturer: | Hirose Electric Co Ltd |
In Stock 2 pcs
|
|
---|---|---|---|
Datasheet: | H/MS08A22-22S-DT12D(73) | ||
Product Category: | Circular Connectors | Reference Price (In US Dollars) | 1pcs |
Description: | CONN PLUG FMALE 4POS SOLDER CUP | $64.77 |
Fill out the below form and we will contact you as soon as possible.
Product Parameter
- Color
- Black
- Series
- H/MS
- Features
- Backshell, Cable Clamp, Coupling Nut, Ground
- Packaging
- Bulk
- Shielding
- Unshielded
- Orientation
- N (Normal)
- Part Status
- Active
- Termination
- Solder Cup
- Applications
- -
- Shell Finish
- Black Chromate
- Cable Opening
- 0.512" ~ 0.626" (13.00mm ~ 15.90mm)
- Mounting Type
- Free Hanging (In-Line), Right Angle
- Connector Type
- Plug, Female Sockets
- Fastening Type
- Threaded
- Shell Material
- Aluminum Alloy
- Voltage Rating
- -
- Insert Material
- Polyphenylene Sulfide (PPS)
- Shell Size, MIL
- -
- Contact Material
- Copper Alloy
- Mounting Feature
- -
- Ingress Protection
- IP67/68 - Dust Tight, Waterproof
- Number of Positions
- 4 (3 + PE)
- Shell Size - Insert
- 22-22
- Current Rating (Amps)
- -
- Operating Temperature
- -40°C ~ 125°C
- Contact Finish - Mating
- Silver
- Backshell Material, Plating
- Aluminum Alloy, Black Chromate
- Material Flammability Rating
- UL94 V-0
- Contact Finish Thickness - Mating
- 78.7µin (2.00µm)
