Lanka Micro
MF-FSMF010X-2
| Manufacturer: | Bourns, Inc. |
In Stock 11185 pcs
|
|
|---|---|---|---|
| Datasheet: | MF-FSMF010X-2 | ||
| Product Category: | PTC Resettable Fuses | Reference Price (In US Dollars) | 1pcs |
| Description: | PTC RESET FUSE 15V 100MA 0603 | Inquiry | |
Fill out the below form and we will contact you as soon as possible.
You May Also Be Interested In
Product Parameter
- Type
- Polymeric
- Series
- Multifuse®, MF-FSMF
- Ratings
- -
- Approvals
- cURus, TUV
- Packaging
- Digi-Reel®
- Part Status
- Active
- Lead Spacing
- -
- Time to Trip
- 1s
- Current - Max
- 40A
- Mounting Type
- Surface Mount
- Voltage - Max
- 15V
- Package / Case
- 0603 (1608 Metric), Concave
- Thickness (Max)
- 0.026" (0.65mm)
- Base Part Number
- MF-FSMF
- Size / Dimension
- 0.065" L x 0.033" W (1.65mm x 0.85mm)
- Current - Trip (It)
- 300mA
- Height - Seated (Max)
- -
- Operating Temperature
- -40°C ~ 85°C
- Current - Hold (Ih) (Max)
- 100mA
- Resistance - Initial (Ri) (Min)
- 900 mOhms
- Resistance - Post Trip (R1) (Max)
- 6 Ohms
