SRP4012TA-R60M
| Manufacturer: | Bourns, Inc. | In Stock 5084 pcs | |
|---|---|---|---|
| Datasheet: | SRP4012TA-R60M | ||
| Product Category: | Fixed Inductors | Reference Price (In US Dollars) | 1pcs |
| Description: | FIXED IND 600NH 5.3A 26 MOHM SMD | Inquiry | |
Fill out the below form and we will contact you as soon as possible.
You May Also Be Interested In
Product Parameter
- Type
- Wirewound
- Series
- SRP4012TA
- Ratings
- AEC-Q200
- Q @ Freq
- 10 @ 100kHz
- Packaging
- Digi-Reel®
- Shielding
- Shielded
- Tolerance
- ±20%
- Inductance
- 600nH
- Part Status
- Active
- Mounting Type
- Surface Mount
- Package / Case
- 2-SMD
- Material - Core
- Carbonyl Powder
- Base Part Number
- SRP4012TA
- Size / Dimension
- 0.175" L x 0.160" W (4.45mm x 4.06mm)
- DC Resistance (DCR)
- 26mOhm Max
- Current - Saturation
- 6A
- Current Rating (Amps)
- 5.3A
- Height - Seated (Max)
- 0.047" (1.20mm)
- Operating Temperature
- -40°C ~ 150°C
- Supplier Device Package
- 2-SMD
- Frequency - Self Resonant
- 117MHz
- Inductance Frequency - Test
- 100kHz
