MF-R055/90-2
| Manufacturer: | Bourns, Inc. |
In Stock 2491 pcs
|
|
|---|---|---|---|
| Datasheet: | MF-R055/90-2 | ||
| Product Category: | PTC Resettable Fuses | Reference Price (In US Dollars) | 1pcs |
| Description: | PTC RESET FUSE 90V 550MA RADIAL | $0.95 | |
Fill out the below form and we will contact you as soon as possible.
You May Also Be Interested In
Product Parameter
- Type
- Polymeric
- Series
- Multifuse®, MF-R/90
- Ratings
- -
- Approvals
- cURus, TUV
- Packaging
- Cut Tape (CT)
- Part Status
- Active
- Lead Spacing
- 0.201" (5.10mm)
- Time to Trip
- 60s
- Current - Max
- 10A
- Mounting Type
- Through Hole
- Voltage - Max
- 90V
- Package / Case
- Radial, Disc
- Thickness (Max)
- -
- Base Part Number
- MF-R055
- Size / Dimension
- 0.429" Dia x 0.142" T (10.90mm x 3.60mm)
- Current - Trip (It)
- 1.1A
- Height - Seated (Max)
- 0.657" (16.70mm)
- Operating Temperature
- -40°C ~ 85°C
- Current - Hold (Ih) (Max)
- 550mA
- Resistance - Initial (Ri) (Min)
- 450 mOhms
- Resistance - Post Trip (R1) (Max)
- 2 Ohms
